GENERAL
Master Level Control
2 Drawbar sets per manual
Pedal drawbars
126 Program Locations
Live Buffer
ORGAN SECTION
Classic Tonewheel Organ, Vox Continental- and Farfisa-models with full polyphony
Pipe Organ, baroque style with 21 stops. Polyphony depends on the stops being used
Bass models (tonewheel, synthbass and pipe organ bass)
6 Drawbar Presets per Program Location
Percussion Controls
Vibrato/Chorus/Tremulant Control
PIPE ORGAN STOPS AND COUPLERS
Swell (Manual II) Great (Manual I) Pedal Couplers
Fugara 8 Principal 8 Subbas 16 PED/GR. Low
Rohrflöte 8 Gamba 8 Fagot 16 SW 16/GR
Principal 4 Gedackt 8 Gedackt 8 SW/GR
Spitzflöte 4 Octava 4 Swell 16
Nasat 3 Rohrflöte 4 Swell 4
Flöte 2 Qvinta 3 SW/PED
Vox Celeste Octava 2 GR/PED
Scharf II-III Mixtur III-IV
Oboe 8 Trumpet 8
EFFECT SECTION
3-band Equalizer
Overdrive
3 types of Speaker Simulations - including two Rotary Speaker models (122, 122 Close and 145) with selectable speed (slow - stop - fast)
Delay - with feedback and tap-tempo function
Reverb - 6 algorithms
KEYBOARD
2 x 61 Medium Weighted Waterfall Keys
CONNECTIONS
Stereo Headphone Output - ¼", 6,35 mm stereo jack
2 Line Level Audio Outputs, L & R - ¼", 6,35 mm jacks, unbalanced
High Level Outputs:
- 11-pin Leslie* standard connector
- ¼", 6,35 mm jack
Monitor Input - 1/8", 3,5 mm stereo jack
Sustain Pedal Input - ¼", 6,35 mm jack. Use a momentary pedal, like e.g, Roland DP-2, DP-6, Yamaha FC-4, FC-5, Fatar VFP1-25 etc.
Rotor Control Input - ¼", 6,35 mm jack. Use a momentary pedal or a switch type pedal or the Half Moon switch (accessory, not included)
Swell Pedal Input - ¼", 6,35 mm TRS stereo jack. Use a Control/Expression pedal like e.g. Yamaha FC-7, Roland EV-5 etc.
MIDI In - 5 pin DIN connector
MIDI Out - 5 pin DIN connector
Bass Pedal MIDI In - 5 pin DIN connector
USB - type B connector
IEC C14 power connector
Connections
INCLUDED ACCESSORIES
Owner's Manual
Power cord
DIMENSIONS
966 mm (38.0"), 163 mm (6.4"), 445 mm (17.5")
WEIGHT
16 kg (35 lbs.)
